Product Overview

570AILF

IC MULTIPLIER/ZDB 8-SOIC

Lead free / RoHS Compliant

1+	$4.20
10+	$3.75
97+	$3.375
194+	$3.075
291+	$2.775
582+	$2.49
1067+	$2.10
2522+	$1.995
5044+	$1.92

Product Specifications

Part No.	570AILF
Manufacturer	IDT (Renesas Electronics Corporation)
Description	IC MULTIPLIER/ZDB 8-SOIC
Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	Out stock
Datasheets	570AILF.pdf
Voltage - Supply	4.75 V ~ 5.25 V
Type	Fanout Distribution, Spread Spectrum Clock Generator, Zero Delay Buffer
Supplier Device Package	8-SOIC
Series	ClockBlocks™
Ratio - Input:Output	1:2
Packaging	Tube
Package / Case	8-SOIC (0.154", 3.90mm Width)
PLL	Yes
Output	CMOS
Other Names	800-2373-5 ICS570AILF ICS570AILF-ND
Operating Temperature	-40°C ~ 85°C
Number of Circuits	1
Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	12 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Input	Clock
Frequency - Max	170MHz
Divider/Multiplier	Yes/Yes
Differential - Input:Output	No/No
Base Part Number	ICS570

Out stock Minimum 1
